Design and Tuning

Design antennas or arrays at desired frequency; add R, L, and C components to antenna feed or arbitrary locations on antenna surface; use AI-based models to explore design space and tune antennas

Design antennas or arrays from the catalogs to resonate at specified frequencies. Use AI-based models of antenna catalog elements to explore the design space, analyze and tune the antenna for your application.

Loading antenna elements allows you to change the electrical properties of the antenna. Lumped elements are used to increase the antenna bandwidth without changing the dimensions of the antenna. Antenna loading involves adding a lumped inductor, capacitor or resistor. You can add these lumped elements to the antenna feed or arbitrary positions on the antenna surface.

Objects

AIAntennaEnable catalog antenna elements for AI-based design space exploration (Since R2023b)
lumpedElementLumped element circuit to load antenna

Functions

designDesign prototype antenna or arrays for resonance around specified frequency or create AI-based antenna from antenna catalog objects
showDisplay antenna, array structures, shapes, or platform
