Acquisition Using GigE Vision Hardware
Image Acquisition Toolbox™ includes a separate interface for use with GigE Vision compliant cameras. This interface is designed for GigE Vision cameras and supports more GigE-specific functionality.
You can continue to use the GigE Vision adaptor (
gige) with the
videoinput object, or you can use the
gigecam object, which takes advantage of GigE
properties and features and is more consistent with GigE Vision conventions for displaying properties and managing
For more information about choosing the interface, see GigE Vision Acquisition: gigecam Object vs. videoinput Object.
The documentation for the Image Acquisition Toolbox Support Package for GigE Vision Hardware is also included in the support package and can be accessed directly from the support package. The Setup and Configuration section in the support package documentation includes a configuration guide for doing GigE Vision hardware acquisition on Windows® systems.
Note: The functionality for all supported hardware is now available via the Support Package Installer. Starting with R2014a, each adaptor is available separately through the Support Package Installer, and you must install the appropriate support packages to use the toolbox with your hardware. For more information, see Image Acquisition Support Packages for Hardware Adaptors.
|List of GigE Vision cameras connected to your system|
|List of commands available for GigE Vision camera|
|Execute command on GigE Vision camera|
|Acquire single image frame from GigE Vision camera|
|Preview of live video data|
|Close Video Preview window|
Examples and How To
gigecamlist function to
return the list of available GigE Vision Compliant cameras connected
to your system.
One of the main advantages of using the
gigecam object for image
acquisition is the advanced property features of GigE Vision Compliant hardware.
gigecam object and acquire
The GigE Vision and GenICam™ GenTL interfaces offer advanced property support.
The Image Acquisition Toolbox includes a separate interface for use with GigE Vision Compliant cameras. You can continue to use the GigE Vision adaptor (
gige) with the
object, or you can use the
gigecam object, which takes advantage of
GigE properties and features.
Try these tips if you have problems using the toolbox with GigE Vision image acquisition devices. Information is provided for all platforms.
