Inductor

Model inductor for circuit envelope analysis

  • Library:
  • RF Blockset / Circuit Envelope / Elements

Description

The Inductor block models an inductor in circuit envelope environment.

Parameters

expand all

Inductance value, specified as a real number. Specify the units of the capacitance from the corresponding drop-down menu.

If you set this parameter to a value between 0 and 1e-18 H, the block uses a value equal to 1e-18 H during simulation. By default, the value is 1e-9 H.
