Thermal Liquid Library
Thermal liquid networks undergo temperature and viscosity changes due to processes internal and external to a block or network. Fluid properties are a function of pressure and temperature. Heat exchangers are located in the Fluid Network Interfaces library.
If a specific component does not yet exist in a domain library, you can build your own using the Simscape™ language. For more information, see Creating Custom Components.
Linear actuators for one- and two-way motion control
- Pipes and Fittings
Conduits for fluid transport
- Pumps and Motors
Fixed- and variable-displacement devices for mechanical-hydraulic energy conversion
- Tanks and Accumulators
Pressurized chambers for hydraulic energy storage and pulsation smoothing
Preset fluid properties for thermal liquid networks
- Valves and Orifices
Variable local restrictions for fluid flow control
