Actuators

Linear and rotary actuators for one- and two-way motion control

Use these blocks to model actuation in the isothermal liquid domain.

Simscape Blocks

Double-Acting Rotary Actuator (IL)Double-acting rotary actuator in an isothermal liquid system (Since R2020a)
Double-Acting Actuator (IL)Linear conversion of pressure differential to actuation in an isothermal liquid system (Since R2020a)
Rotating Single-Acting Actuator (IL)Actuator on a rotating shaft in an isothermal liquid network (Since R2020a)
Single-Acting Rotary Actuator (IL)Double-acting rotary actuator in an isothermal liquid system (Since R2020a)
Single-Acting Actuator (IL)Single-acting linear actuator in an isothermal liquid system (Since R2020a)
Cylinder Cushion (IL)Cushion in cylinder in isothermal liquid network (Since R2020a)
Cylinder Friction (IL)Adds friction to cylinders with moving components (Since R2020a)
Rotating Cylinder Force (IL)Centripetal pressure gradient for components in an isothermal liquid system (Since R2020a)
