polystab

Stabilize polynomial

Syntax

b = polystab(a)

Description

polystab stabilizes a polynomial with respect to the unit circle; it reflects roots with magnitudes greater than 1 inside the unit circle.

b = polystab(a) returns a row vector b containing the stabilized polynomial. a is a vector of polynomial coefficients, normally in the z-domain:

A(z)=a(1)+a(2)z1++a(m+1)zm.

Examples

collapse all

Use the window method to design a 25th-order FIR filter with normalized cutoff frequency 0.4π rad/sample. Verify that it has linear phase but not minimum phase.

h = fir1(25,0.4);

h_linphase = islinphase(h)
h_linphase = logical
   1

h_minphase = isminphase(h)
h_minphase = logical
   0

Use polystab to convert the linear-phase filter into a minimum-phase filter. Plot the phase responses of the filters.

hmin = polystab(h)*norm(h)/norm(polystab(h));

hmin_linphase = islinphase(hmin)
hmin_linphase = logical
   0

hmin_minphase = isminphase(hmin)
hmin_minphase = logical
   1

phasez(h,1)
hold on
phasez(hmin,1)
hold off
legend("h","hmin")

Verify that the two filters have identical magnitude responses.

[hf,f] = freqz(h,1);
hfmn = freqz(hmin,1);

plot(f/pi,mag2db(abs([hf hfmn])))
grid
legend("h","hmin")

Algorithms

polystab finds the roots of the polynomial and maps those roots found outside the unit circle to the inside of the unit circle:

v = roots(a);
vs = 0.5*(sign(abs(v)-1)+1);
v = (1-vs).*v + vs./conj(v);
b = a(1)*poly(v);

Version History

Introduced before R2006a
