Support for Fixed Reference Design

Create SoC model for fixed reference design, edit created model to include algorithm, simulate and/or build and deploy model on MPSoC, RFSoC, and Versal® ACAP devices

This workflow enables algorithm and system designers to generate an HDL IP core and integrate it into a fixed reference design for rapid prototyping. Create an SoC model based on the selected reference design for the supported Xilinx® MPSoC, RFSoC, and Versal ACAP devices by using the SoC Model Creator tool. Use the created model as a template to design and simulate your FPGA algorithm and processor algorithm. Then, generate a bitstream and host I/O model, build a software application, and program the board by using the SoC Builder tool.



SoC Model CreatorCreate SoC model based on selected reference design (Since R2021b)


soc.RFDataConverterConfigure the RF Data Converter on the RFSoC device from MATLAB (Since R2020b)
