Use the spacecraft blocks, available in the Aerospace Blockset > Spacecraft sublibrary, to model, simulate, and visualize the dynamics of spacecraft.
|Model attitude dynamics of one or more spacecraft (Since R2023a)
|Calculate shortest quaternion rotation (Since R2020b)
|Model CubeSat vehicle (Since R2019a)
|Eclipse Shadow Model
|Calculate fraction of solar disk visible at inertial positions (Since R2023b)
|Propagate orbit of one or more spacecraft (Since R2020b)
|Model dynamics of one or more spacecraft (Since R2021b)
- Model Spacecraft
Model, simulate, and visualize the motion and dynamics of spacecraft using spacecraft dynamics, orbit propagator, and CubeSat blocks.
- Model and Simulate CubeSats
Model, simulate, analyze, and visualize the motion and dynamics of spacecraft.
- Getting Started with the Spacecraft Dynamics Block
This example shows how to model six degree-of-freedom rigid-body dynamics of a spacecraft or constellation of spacecraft with the Spacecraft Dynamics block from Aerospace Blockset™.
- Constellation Modeling with the Orbit Propagator Block
Propagate the orbits of a constellation of satellites and compute and visualize access intervals between the individual satellites and several ground stations.
- Developing the Apollo Lunar Module Digital Autopilot
Develop Apollo Lunar Module digital autopilot using Simulink® and Aerospace Blockset™.
