Phase delay of digital filter

`phasedelay(___)`

plots the phase
delay response versus frequency.

The *phase delay response* of a filter corresponds to the time delay
that each frequency component experiences as the input signal passes through the system. The
`phasedelay`

function returns the phase delay response and the frequency
vector of the filter

$$H({e}^{j\omega})=\frac{B({e}^{j\omega})}{A({e}^{j\omega})}=\frac{\text{b}(1)+\text{b}(2){e}^{-j\omega}+\dots +\text{b}(\text{m}+1){e}^{-jm\omega}}{\text{a}(1)+\text{a}(2){e}^{-j\omega}+\dots +\text{a}(\text{n}+1){e}^{-jn\omega}}$$

given numerator and denominator coefficients in inputs
`b`

and `a`

.

`designfilt`

| `digitalFilter`

| `freqz`

| FVTool | `phasez`

| `grpdelay`
