Deep Learning HDL Toolbox™ generates a deep learning (DL) processor IP core and builds the FPGA bitstreams for the supported FPGA boards. For more information, see Generate Custom Processor IP and Generate Custom Bitstream.
You can accelerate the integration of the generated DL processor IP core into your system design by:
Generating the DL Processor IP core.
Using the compiler generated external memory buffer allocation.
Formatting the input and output external memory data.
Creating the AXI4 register maps. The AXI4 registers allow MATLAB® to control and program the DL processor IP core.
Learn about the generated deep learning processor IP core.
Determine the target-specific external memory offsets based on your network and hardware design.
Define the input and output external memory data format.
Use MATLAB or other AXI4 master devices to control and program the deep learning processor IP core.
